Power Source
|
100 – 240 V AC, 50/60 Hz
|
|
Rated Output
|
120 W
|
|
Power Consumption
|
44 W (AC operation at 1/8 maximum output without clip) (EN60065)
|
|
Frequency response
|
50 Hz – 20 kHz
|
|
Total Harmonic Distortion
|
Under 1 % at 1 kHz, 1/3 rated power
|
|
Signal to Noise Ratio
|
Over 60 dB
|
|
Input
|
MIC 1: 1 mV (-60 dB*), 600 Ω, Balanced, phone jack, selectable to RJ45 MIC 2 – 3: 1 mV (-60 dB*), 600 Ω, Balanced, phone jack MIC 4: 1 mV (-60 dB*), 600 Ω, Balanced, phone jack, selectable to AUX 1 AUX 1: 100 mV (-20 dB*), 10 kΩ, Unbalanced, RCA pin jack, selectable to MIC 4 AUX 2: 100 mV (-20 dB*), 10 kΩ, Unbalanced, RCA pin jack MP3: LED Display, Support USB, SD/MMC card (up to 32GB), Bluetooth, Radio FM, Record
|
|
Output
|
Speaker out: Speaker Output in screw type terminal Direct line (selectable): 83 Ω (100 V) or 4 Ω Rec out: 0 dB*, 600 Ω, unbalanced, RCA pin jack 5-Zone Selector (all zones simultaneously selectable)
|
|
Phantom Power
|
DC +21 V (MIC 1)
|
|
Zone Selection
|
5 zone selector (all zones simultaneously selectable)
|
|
Tone Control
|
Bass: ±10 dB at 100 Hz / Treble: ±10 dB at 10 kHz
|
|
Finish
|
ContenPanel: ABS resin, Black Case: Steel Plate, Black
|
|
Dimensions
|
420(W) × 100.9(H) × 357(D) mm
|
|
Weight
|
4.6 kg
|
A-3212DMZ Digital Mixer Amplifier
WhatsApp For Pricing
Toa a-3212DMZ Digital Mixer Amplifier
Available in 120W, 240W and 480W to suit any applications
• Universal power input: 100 – 240 V
• Feature MP3 Player, FM Radio, Bluetooth and Zone Selection
• Up to 5 MIC, 2AUX
• Fan cooling system to prevent over-heating* *for selected models
• Booster Amplifier with 100 V Line Input
Share it:
Features
