Model (Part Number)
|
ELX112P (120V – F01U170820) (230V – F01U170817)
|
ELX115P (120V – F01U170821) (230V – F01U170818)
|
ELX118P (120V – F01U170822) (230V – F01U170819)
|
|
Freq. Response (-3 dB)
|
60 Hz – 18 kHz1
|
56 Hz – 18 kHz1
|
42 Hz – 100 Hz2
|
|
Freq. Range (-10 dB)
|
50 Hz – 20 kHz1
|
44 Hz – 20 kHz
|
32 Hz – 130 Hz2
|
|
Max. Measured SPL3 :
|
132 dB
|
134 dB
|
134 dB
|
|
Coverage (Horiz. x Vert.)
|
90° x 50°
|
Omnidirectional
|
|
|
Power Rating
|
1000W
|
700W
|
|
|
LF Transducer
|
(1) EVS-12K, 305mm (12”) Woofer
|
(1) EVS-15K, 381mm (15”) Woofer
|
(1) EVS-18K, 457mm (18”) Woofer
|
|
HF Transducer
|
DH-1K, 39mm (1.5”) Titanium Diaphragm Compression Driver
|
N/A
|
|
|
Crossover Frequency
|
1.7 kHz
|
100 Hz
|
|
|
Connectors
|
(2) XLR/TRS Combo Jacks, (1) Stereo RCA, (1) XLR Link Output
|
(1) XLR/TRS Combo Jack, (1) XLR Link Output
|
|
|
Enclosure Material
|
9-ply, 15mm Plywood, Internally Braced, with Texured Paint
|
||
|
Grille
|
18GA Steel with Black Powdercoat
|
||
|
Dimensions (H x W x D)
|
607mm x 362mm x 340mm (23.89” x 14.25” x 13.41”)
|
708mm x 432mm x 382mm (27.89” x 17.02” x 15.05”)
|
661mm x 507mm x 574mm (26.02” x 19.98” x 22.60”)
|
|
Net Weight
|
16.8 kg (36.9 lbs)
|
22.5 kg (49.5 lbs)
|
31.3 kg (68.9 lbs)
|
|
Shipping Weight
|
20.7 kg (45.5 lbs)
|
27.2 kg (59.8 lbs)
|
38.0 kg (83.6 lbs)
|
|
Accessories
|
TSS-1, Aluminum Tripod Stand TSP-1, Tripod Kit, Includes (2) Tripod Stands and Carrying Case ASP-1, Steel Subwoofer Stand
|
ASP-1, Steel Subwoofer Stand
|
|
EV-ELX-115P
WhatsApp For Pricing
EV-ELX-115P Electro Voice Speaker
– The 15″ woofer and a 1.5″ titanium compression driver provide crisp, natural audio with a wide frequency response
– The speaker has a 1000W Class-D amplifier to provide a strong, distortion-free performance, while keeping weight and heat to a minimum without needing fans
– The plywood cabinet can be placed vertically or horizontally for terrific versatility for PA or stage monitoring applications
– The standard 35mm pole socket lets you create stacks or mount the speaker on top of a subwoofer
– A pair of XLR/TRS combo inputs, a stereo RCA input, and an XLR link output allow you to connect to virtually any sound system
– The steel grille protects the driver elements and provides a sleek look
– Integrated carrying handles provide convenient transportation
