| Max. Measured SPLĀ³ |
137 dB |
| Recommended HP Freq. |
35 Hz |
| Coverage (Horiz. x Vert.) |
90Ā° x 50Ā° |
| Power Handling |
600W Continuous, 2400W Peak |
| LF Transducer(s) |
(2) EVS-15K, 381mm (15″) Woofers |
| HF Transducer |
DH-1K, 39mm (1.5″) Titanium Diaphragm Compression Driver |
| Crossover Frequency |
1.7 kHz |
| Nominal Impedance |
4 Ohms |
| Minimum Impedance |
3.7 Ohms |
| Connectors |
Dual NL4 |
| Enclosure Material |
9-ply, 15mm Plywood, Internally Braced, with Texured Paint |
| Grille |
18GA Steel with Black Powdercoat |
| Dimensions (H x W x D) |
1154mm x 432mm x 501mm (45.44″ x 17.02″ x 19.73″) |
| Net Weight |
40.7 kg (89.6 lbs) |
| Shipping Weight |
48.4 kg (106.6 lbs) |
