Freq. Range (-10 dB)
|
42Hz – 20kHz
|
|
Freq. Response (-3 dB)
|
50Hz – 16kHZ
|
|
Long Term Pwr Handling 1
|
400W LF / 150W MF/HF
|
|
Short Term Pwr Handling 1
|
1600W LF / 600W MF/HF
|
|
Sensitivity (1W / 1m)
|
980B LF / 10508 MF/HF
|
|
Impedance
|
8 ohms LF / 12 ohms MF/HF
|
|
Max. Calc. SPL Output
|
130dB @ 1m
|
|
Horizontal Coverage
|
75°
|
|
Vertical Coverage
|
50° (Up 15°, Down 35°)
|
|
LF to MF Crossover
|
500 Hz
|
|
Passive Crossover Freq
|
1.2 kHz
|
|
LF Transducer
|
15-inch DL15ST
|
|
MF/HF Transducers
|
MF8 8-inch MF / DH7 3-inch HF
|
|
Enclosure
|
Trapezoidal 13-ply (18mm) Baltic Birch (15° Side Angles)
|
|
Suspension
|
L Track w/Ancra fitings
|
|
Connoctors
|
(2) Neutrik Speakon NLA’s
|
|
Q and DI
|
Q-12/DI-108
|
|
Recommended Controller
|
Dx38
|
|
Grille
|
Powder Coated Steel, Fabric backed
|
|
Dim (H X W x D) in
|
415″ x 18.4″ x 19.12″
|
|
Dim (H X W x D) mm
|
1054 mm x 467 mm x 485 mm
|
|
Net Weight
|
97 Ibs (44.09 kg)
|
|
Shipping Weight
|
105 Ibs (47.72 kg)
|
EV-QRx 153-75
WhatsApp For Pricing
EV-QRx-153-75 Electro Voice Speaker
• 8-inch MF horn loaded for 75o x 50o pattern
control to 500 Hz
• 3-inch DH7 HF compression driver
• 15-inch DL15 woofer is loaded into vented
enclosure
• Asymmetric MF and HF horns have
+15o / -35o
coverage
• RMDTM – Ring-Mode Decoupling for vocals
and mids with superb fidelity at any listening
level
• The EV P1202 Precision Series Amplifier and
M153 module are designed to power the
QRx153 perfectly
• L-track rigging is installed on top and
bottom of the enclosure
