| Model |
T-B20 |
T-B40 |
T-B60 |
| Rated Output Power |
20W |
40W |
60W |
| Speaker Output |
4~16Ω/100V |
| Input Sensitivity& Source |
MIC Input: +5mV, unbalanced 6.3 connector |
| Impedance |
AUX Input: 350mV, unbalanced RCA connector |
| Tone |
Bass: 100Hz±10dB, Treble: 10KHz±10dB |
| Frequency Response |
80Hz~16KHz(-3dB) |
| SNR |
≥75dB |
| T.H.D |
Rated power output, distortion rate≤1% |
| Priority Function |
MIC1 input has priority than other input |
| Protection |
Overheating protection, short circuit protection, overload protection |
| Input Power |
~220V 50Hz |
| Power Consumption |
40W |
80W |
120W |
| Dimension |
284 x 188 x 66.5mm |
| Weight |
2.8Kg |
3.5Kg |
4.2Kg |
