ITC T-77500 Network Audio Adapter
Model: T-77500
Network Interface: Standard RJ45 input
Transmission Rate: 100Mbps
Support Protocol: TCP/IP,UDP,IGMP(Multicast)
Audio Format: MP3
Audio Mode: 16 bit CD quality
Sampling Rate: 8K~48KHz
EMC Input Sensitivity: 775mV (Unbalance)
AUX Input Sensitivity: 350mV (Unbalance)
MIC Input Sensitivity: 5mV (Unbalance)
AUX Output Amplitude: 1000mV 2 lotus flower output interface
AUX Output Impedance: 470Ω
Treble Adjustment Range: ±10dB
Bass Adjustment Range: ±10dB
Rated Power: 500W
Power Consumption: 750W
Standby Power Consumption: ＜3W
Frequency Response: 80Hz~16KHz +1/-3dB
Harmonic Distortion: ≤1%
SNR: ＞65dB
Output Method: 4 ~ 16Ω constant resistance output,
70V / 100V constant pressure output
Circuit Protection: DC output, overload, over temperature,
short circuit protection
Working Temperature: 5℃~40℃
Working Environment Humidity: 20% ~80% relative humidity, no condensation
Input Power: ~220-240V 50/60Hz
Size: (484 x 303 x 88mm) (484 x 359 x 132mm)
