SP-2 12-inch 250 Watt Speaker EV ELX-112
Discover the best quality JBL CV1070 is a compact 10-inch loudspeaker engineered for clear, consistent sound in a wide range of commercial installations. Featuring high SPL output, precision driver integration, and a sleek, durable design, it’s ideal for restaurants, halls, cafés, Masjids, schools, auditoriums, and event spaces. AB Audio Visual Pakistan proudly offers JBL speakers send emailto sales@abaudiovisual.pk today and get a free quote!
| Specifications | Details |
|---|---|
| System Type | 10”, 2-way, bass-reflex |
| Frequency Range (-10dB) | 50 Hz – 20 kHz |
| Frequency Response (±3 dB) | 85 Hz – 18 kHz |
| System Sensitivity (1w @ 1m) | 95 dB</td |
| Nominal Impedance | 8 Ω |
| Maximum SPL (1m) | 120 dB continuous (126 dB peak) |
| Power Rating | 300 W / 600 W / 1200 W |
| Coverage | 100° × 70° (H × V) |
| LF Driver | 1 × 10” woofer |
| HF Driver | 1 × 2414H-C tweeter |
| Enclosure | Trapezoid, 15 mm plywood |
| Suspension | 15 × M10 threaded suspension points |
| Finish | Textured paint, black. White (-WH) available on request |
| Grille | Powder-coated 1.5 mm perforated cold rolled steel |
| Input Connector | Dual NL4MP Neutrik Speakon® (loop-through) |
| Dimensions (H × W × D) | 535 × 310 × 329 mm (21.0 × 12.2 × 13.0 in) |
| Net Weight | 13.5 kg (29.8 lbs) |
