| Enclosure |
Sealed Type |
| Rated Input |
40 W |
| Rated Impedance |
100 V line: 250 Ω (40 W), 500 Ω (20 W), 1 kΩ (10 W), 2 kΩ (5 W) 70 V line: 250 Ω (20 W), 500 Ω (10 W), 1 kΩ (5 W), 2 kΩ (2.5 W) |
| Sensitivity |
93 dB (1 W, 1 m) |
| Frequency Response |
150 Hz – 16,000 Hz |
| Speaker Component |
10 cm cone-type × 4 |
| Input Terminal |
Push-In terminal |
| Finish |
Enclosure: HIPS, white Punched Net: Surface-tread steel plate, white, paint Speaker Bracket: Aluminum die-cast, white, paint Joint Bracket, Wall Bracket: Steel plate, t1.6, white, paint |
| Dimensions |
135 (W) × 498 (H) × 128 (D) mm |
| Weight |
3.5 kg (unit only) |
| Accessory |
Speaker Bracket x 1, Joint Bracket x 1, Wall Bracket x 1, Fixing Bolt (M5 x 60) x 1, Hexagon Bolt (M6 x 12) (with plain washer and spring washer) x 2, Machine Screw (M5 x 20) (with plain washer and spring washer) x 2, Hexagon Bolt (M8x 15) x 1 |
| Option |
Speaker Stand: ST-16A |
